Geneerally,there are two main cordage types used in the world：
The American Wire Gauge(AWG) system used in North America, and the European Hatmonized types. In AWG system, the cordage is described in terms of wire gauge size such as 16 or 18 AWG while a Hamonized cordage is expressed by means of mm² (an l8 AWG conductor is comparable 0·75mm² )

Conductor Color Codes

	North America	Harmonized
L=Live(Hot) 火線	Black	Brown
N=Neutral 中線	White	Blue
E=Earth(Ground) 地線	Green	Green / Yellow
4th Conductor 第四條導線	Red
5th Conductor 第五條導線	Yellow
6th Conductor 第六條導線	Orange

Classification for JIS cable

Class

Symbol

Symbols designate the following：

V：polyvinyl chloride

SF：single core flexible cord

TF：twin-twisted flexible cord

FF：flat flexible cord

CTF：cabtyre cord

K：oval

H：heat-resistant insulation

PVC insulated single-core cord

VSF

Heat-resistant PVC insulated single core cord

HVSF

PVC insulated twin-twisted cord

VTF

Heat-resistant PVC insulated twin-core cord

HVTF

PVC insulated flat cord

VFF

Heat-resistant PVC insulated falt cord

HVFF

PVC insulated cabtyre round cord

VCTF

Heat-resistant PVC insulated cabtyre round cord

HVCTF

PVC insulated cabtyre oval cord

VCTFK

Heat-resistant PVC insulated cabtyre oval cord

HVCTFK

Harmonized wire Coding System
This chart illustrates the Harmonization code for cordage "H05VVF 3G 0.75mm²
