❖Product Description
Solid or stranded, tinned or bare copper Conductor, 30-2AWG.
Lead Free PVC Insulation.
Rated temperature: 105°C; Rated voltage: 600 Volts.
Uniform thickness of wire to ensure easy stripping and cutting.

❖Applications
For general purpose internal wiring of electrical, and electrical equiment.

❖Structure & electrical properties
PVC Wire 1015

UL 1015	Range		Conductor		Insulation		Tolerancemm	Maximum Conductor Resistance Ω/km	(VAC/min) Insulation Potential Strength
	Temp ℃	Voltage V	AWG	NO./mm	Thicknessmm	O.Dmm



Stranded	105℃	600V	26	7/0.160	0.76	2.08	± 0.15	152.0	2000
			24	11/0.160	0.76	2.20	± 0.15	88.60
			22	17/0.160	0.76	2.40	± 0.15	62.50
			20	21/0.180	0.76	2.60	± 0.15	39.50
			18	34/0.180	0.76	2.80	± 0.15	24.40
			16	26/0.254	0.76	3.10	± 0.20	15.60
			14	41/0.254	0.76	3.50	± 0.20	9.90
			12	65/0.254	0.76	4.10	± 0.25	6.24
			10	105/0.254	0.76	5.10	± 0.25	4.15
Top-Coated (ATC)	105℃	600V	24	7/0.200	0.76	2.20	± 0.15	88.60
			22	7/0.254	0.76	2.40	± 0.15	62.50
			20	7/0.254	0.76	2.60	± 0.15	39.50
			18	7/0.400	0.76	2.80	± 0.15	24.40
Solid(TA)	105℃	600V	24	1/0.511	0.76	2.15	± 0.15	92.40
			22	1/0.643	0.76	2.30	± 0.15	60.10
			20	1/0.813	0.76	2.45	± 0.15	37.00
			18	1/1.020	0.76	2.72	± 0.15	23.60

1015 / Precision power supply cords
